Intura SunTube55 for pitched roofs

Intura SunTube55 daylight tube for pitched roof applications

• The dome is made of Acrylic (PMMA)
• Easy installation on pitched roofs (pre-mounted with Leadax roofing material).
• Light output is sufficient for a room of up to 25 m² (approximately 5x5 meters).
• The required roof opening should be between 33 and 37 cm in diameter.
• The set is complete for a roof thickness of 41 cm (or 65 cm when combined with the EcoPower insulation element).

The Intura SunTube55 daylight system for pitched roofs is a daylight tube that transports natural light into any desired room in homes or buildings. It is suitable for spaces such as kitchens, utility rooms, bathrooms, hallways, living rooms, workspaces, warehouses, and more.

This Flat Roof Set Includes the Following Components:

• Acrylic dome

• Double-walled insulated aluminium upstand (RAL 9005) for flat roofs, pre-mounted with Leadax roofing = faster installation time

• 2x Tube length of 60 cm (can be shortened as needed)

• 1x Elbow Up to 45° for Intura SunTube35

• EasyClick diffuser for simple finishing

• All necessary mounting materials for installation

This basic set for pitched roofs includes everything needed for installation, provided the roof thickness does not exceed 41 cm (or 65 cm when using the insulation element), measured from the top of the roofing to the bottom of the ceiling.

Extensions & Accessories

• Can be extended with the EcoPower insulation element with HR++ double glazing or HR+++ triple glazing

• Extendable up to 6 meters

• Various accessories available

Intura SunTube Light Tunnel for Pitched Roof – Type 55

A light tunnel is a system that uses internal reflection to bring natural daylight indoors. The benefit of this system is that it only requires a small roof opening compared to, for example, a roof window.

Product Information: Pre-mounted Leadax Roofing Material

Leadax is the new alternative to traditional lead, offering the same properties. It is made from unused PVB residual material, a by-product from the production of laminated glass (e.g., car windows). As a result, it has no harmful impact on health or the environment. Leadax is not only lighter and easier to use but also more cost-effective than traditional lead.
